Hazardous Location Linear
Hazardous Location Linear
Power: 20W, 40W, 60W, 80W
Luminous Flux: 2,660lm - 11,200lm
Luminous Efficacy: 133lm/W - 140lm/W
Color Temperature: 4000K, 5000K
CRI: ≥73
Beam Angle: 120°
Power Supply: Built-In
Input Voltage: 100-277V AC ~ 50/60Hz
Power Factor: ≥ 0.9
Dimmable: No
Housing Material: Aluminum
Lens Material: Tempered Glass
Finish: Gray
Ambient Operating Temperature: -40°C ~ +50°C / -40°F ~ +122°F
Lifetime: ≥ 50,000hrs
UL 1598A Listed
Class I, Division I, Groups C, D
Class I, Division II, Groups A, B, C, D
Class II, Division I, Groups E, F, G
Class II, Division II, Groups E, F, G
Class III
Applications
Certifications
Downloads
Specification Table
EX-1020
2,660lm - 2,800lm
133lm/W - 140lm/W
2 FOOT
B3-U1-G0
23.77lbs
EX-1040
5,320lm - 5,600lm
133lm/W - 140lm/W
2 FOOT / 4 FOOT
B3-U1-G0
23.77lbs / 40.78lbs
EX-1060
7,980lm - 8,400lm
133lm/W - 140lm/W
4 FOOT
B3-U1-G1
40.78lbs
EX-1080
10,640lm - 11,200lm
133lm/W - 140lm/W
4 FOOT
B4-U1-G1
40.78lbs
